Description
AquaSmart 5CD – Intelligent Solar Control with Current Detection
The AquaSmart 5CD is Dontek’s premium solar controller designed for boosted (retrofit) pool heating systems. Engineered with advanced current detection technology, it ensures safe and efficient solar pump operation while delivering precise temperature control and flexible functionality.
Whether you’re upgrading an existing system or installing solar heating for the first time, the AquaSmart 5CD offers smart automation and robust protection for long-term performance.
⚙️ Key Features
- Automatic Temperature Control Maintains your desired pool temperature by activating the solar pump only when solar heating is beneficial.
- Current Detection Technology Integrated current sensing on the AUX power socket ensures the solar pump only operates when the filter pump is running, protecting your system from dry running and energy waste.
- Multi-Mode Functionality Includes Manual, Cooling, and Standby modes to suit seasonal and personal preferences.
- Boosted System Compatibility Ideal for retrofit installations with separate solar and filter pumps.
- Simple User Interface Easy-to-use controls and clear indicators make operation straightforward for homeowners and technicians.
📐 Technical Specifications
| Specification | Details |
|---|---|
| Model | AquaSmart 5CD |
| System Type | Boosted (Retrofit) Solar Heating |
| Operating Modes | Automatic, Manual, Cooling, Standby |
| Temperature Adjustment | Yes |
| Current Detection | AUX socket monitors load before pump activation |
| Power Supply | Standard 240V AC |
| Pump Control | Solar pump operates only with filter pump |
| Installation Type | Wall-mounted, suitable for outdoor use |
| Warranty | 3 Years |
🛠️ Ideal For:
- Homeowners seeking safe, efficient solar heating control
- Pool technicians upgrading or retrofitting systems
- Installers looking for a reliable, intelligent controller with built-in protection
💡 Smart, Safe, Sustainable
With the AquaSmart 5CD, you’re not just heating your pool—you’re protecting your system and maximizing solar efficiency. It’s solar control, elevated.
